Beskrivelse, Tilslutninger, Anmærkning – ABUS SE1010 Key switch incl. ABUS quality cylinder User Manual
Page 23
22
Beskrivelse
Tilslutninger
1 2
2
2
2
3
1
1 Printkortholder
2 Vægbefæstigelse
3 Kabelindføring
Anmærkning:
Den beskrevne kontaktstilling gælder for det tilfælde at husets dæksel er åbent.
Stel til LED (gul)
Kontakt S2
12V spænding til LED
NO
COM
NC
NO
COM
NC
S2
S1
NO
COM
NC
NC
NO
COM
Sabotage
kontakter
Kontakt S1
12V spænding til LED
Stel til LED (rшd)
