Beschrijving – ABUS SE1010 Key switch incl. ABUS quality cylinder User Manual
Page 19
18
Beschrijving
2
2
Afb. 1 huis open
(met printplaat)
Afb. 2 huis zonder printplaat
1 printplaathouder
2 wandbevestiging
3 kabelinvoer
Opmerking:
De beschreven schakelaarstand geldt voor het geval dat het deksel van het huis
open is.
Massa voor LED (geel)
Schakelaar S2
12V spanning voor LED
NO
COM
NC
NO
COM
NC
S2
S1
NO
COM
NC
NC
NO
COM
Sabotage-
contacten
Schakelaar S1
12V spanning voor LED
Massa voor LED (rood)
1 2
2
3
1
