OM−03688 0 SERIES
PAGE B − 2 INSTALLATION
Table 1. Pump Specifications
Pump Type Self-priming, centrifugal with enclosed impeller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suction 4-inch Victaulic" fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Discharge 4-inch Victaulic" fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nominal Capacity See the Performance Curve, Page E-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Impeller Shaft Seal Mechanical self-lubricated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gearbox (Air Shift)
Air Pressure Required at Shift Cylinder 70-140 psi (5,1-10,2 kg/cm @) through 1/4" line . . . .
Gear Ratio 2.56:1 Speed Increase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input shaft Rotation Clockwise (when viewed from the trunnion end) . . . . . . . . . . . . . . . . . . . .
Maximum Input Speed 1950 RPM (See the Performance Curve, Page E-1) . . . . . . . . . . . . . .
Input & Output Shaft Heavy-duty 2-3/4 inch - 10 spline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input & Output Flanges Dana" Heavy-Duty 1800 Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication 68 U.S. ounces (2011 ml) - See LUBRICATION, Section E for SAE grade . . . . .
6 fl. oz. (18 ml) ‘Molykote R M Gear Guard’ (Dow Corning)
Approx. Net Weight (pump and gearbox) 285 pounds (129,3 kg) . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 2. Through Torque Capacity Based On Shaft and Spline Size
Type of Engine Transmission Max Through Torque (ft.-lbs.)
Diesel Automatic 11,000
Manual 10,000
Gasoline Automatic 13,300
Manual 12,300
Pump and Mounting Dimensions
A 40 inch (1016 mm) cross member is provided for
mounting the output end of the gearbox, and a
trunnion mount is provided for the input end. This
design provides a flexible three-point suspension.
The trunnion mount prevents the chassis frame
twist from being transmitted through the gearbox.
See Figure 1 on page B−3 and Figure 2 on page
E−4 for the physical dimensions of the pump.
