OM−03688 0 SERIES
MAINTENANCE & REPAIR PAGE E − 3
PARTS LIST
Pump Model 04E1−GHH
(From S/N 1076270 Up)
ITEM
NO. PART
NAME PART
NUMBER MAT’L
CODE QTY
1 REPAIR PUMP CASING 38222−526 13000 1
2 IMPELLER 8375 1304R 1
3 SEAL ASSEMBLY 25271−192 −−− 1
4 DISCHARGE FLANGE O-RING 25154−244 −−− 1
5 HEX HD CAPSCREW B0805 15991 4
6 LOCKWASHER J08 15991 4
7 DISCHARGE FLANGE 38641−314 13000 1
8 TRUNNION 38151−023 11010 1
9 INPUT FLANGE 24571−912 −−− 1
10 LUBE FITTING S186 −−− 1
11 CAP PLUG 25141−151 −−− 1
12 PUMP CASING O-RING 25152−155 −−− 1
13 BEARING SHIM SET 8545 15990 1
14 OIL SEAL S2007 −−− 1
15 REPAIR GEARBOX ASSY 44161−146 −−− 1
16 STUD C0807 15991 6
17 HEX NUT D08 15991 6
18 PUMP CASING GASKET 38683−464 18000 1
19 PUMP CASING WEAR RING 8464 10018 1
20 IMPELLER SHIM SET 2X 17090 1
21 PUMP CASING DRAIN PLUG P32 10009 1
22 SUCTION HEAD WEAR RING 64H5 10018 1
23 IMPELLER NUT 22565−307 −−− 1
24 SUCTION HEAD 38247−206 13040 1
25 KEY N0405−1/4 15990 1
26 SUCTION HEAD GASKET 8376G 20000 1
27 STUD C0605−1/2 15991 12
28 HEX NUT D06 15991 12
29 OUTPUT FLANGE 24571−912 −−− 1
30 CROSS MEMBER KIT 48123−401 −−− 1
NOT SHOWN:
NAME PLATE 38818−020 13990 1
DRIVE SCREW BM#04−03 17000 4
INSTRUCTION TAG 38817−041 −−− 1
SUCTION STICKER 6588AG −−− 1
DISCHARGE STICKER 6588BJ −−− 1
OPTIONAL:
BRONZE FITTED:
−IMPELLER
8375 14000 1
−WEAR RING 8464 14000 1
−WEAR RING 64H5 14000 1
INDICATES PARTS RECOMMENDED FOR STOCK
