OM−03688 0 SERIES
MAINTENANCE & REPAIR PAGE E − 5
PARTS LIST
44161−146 Repair Gearbox Assembly
1 AIR SHIFT COVER ASSY 44231−501 −−− 1
2 −SHIFTER SHAFT ASSY 44231−502 −−− 1
3 −OIL SEAL 25228−506 −−− 1
4 −O-RING BOSS PLUG 38649−039 15079 1
5 −SHIFTER COVER 38354−041 10000 1
6 −SOC HD CAPSCREW 21472−478 −−− 2
7 −SHIFTER FORK 38584−003 1101X 1
8 −AIR VENT S1703 −−− 1
9 −O-RING 25154−212 −−− 1
10 −CYLINDER GASKET 38681−215 19060 1
11 −AIR CYLINDER O-RING 25154−326 −−− 1
12 −CYLINDER 31417−063 14000 1
13 −CYLINDER CAP GSKT 38681−215 19060 1
14 −CYLINDER CAP 38326−002 10000 1
15 −HEX HD CAPSCREW 21472−087 −−− 2
16 SHIFTER COVER GSKT 38673−312 19060 1
17 DRIVE GEAR 38541−404 16000 1
18 RETAINING RING S1165 −−− 1
19 SPACER 31134−103 15210 1
20 BALL BEARING 23231−515 −−− 1
21 BALL BEARING 23251−019 −−− 1
22 HEX HD CAPSCREW 21472−139 −−− 4
23 OIL SEAL 25228−648 −−− 1
24 BEARING CAP 38325−014 10000 1
25 INPUT SHAFT 38521−715 16000 1
26 RETAINING RING 24125−051 −−− 1
27 BALL BEARING 23231−515 −−− 1
28 SPACER/SLINGER 44148−007 −−− 1
29 BEARING CAP GASKET 38687−548 19060 1
30 NAME PLATE 38818−123 13000 1
31 DRIVE SCREW BM#04−03 17000 2
32 HEX HD CAPSCREW 21472−070 −−− 7
33 BEARING CAP 38325−015 10000 1
34 ROLLER BEARING 23529−001 −−− 1
35 IDLER SHAFT 31711−049 16000 1
36 WOODRUFF KEY AV1009 15990 1
37 IDLER GEAR 38541−405 16000 1
38 BALL BEARING S1088 −−− 1
39 IMPELLER SHAFT 38521−201 16000 1
40 BEARING CAP GASKET 38688−018 19060 1
41 GEARBOX HOUSING 38313−026 10000 1
42 BALL BEARING S1088 −−− 1
43 ROLLER BEARING 23529−001 −−− 1
44 SLIDING CLUTCH 38521−714 16000 1
45 ROLLER BEARING 23528−002 −−− 1
46 TAIL SHAFT ASSY 44732−902 −−− 1
47 −RETAINING RING S1165 −−− 1
48 −ROLLER BEARING 23529−021 −−− 1
49 −BEARING RETAINER 38325−012 10000 1
50 −RETAINING RING 24125−051 −−− 1
51 −GEAR 38541−004 15000 1
52 −BEARING CAP GASKET 38687−549 19060 1
53 −HEX HD CAPSCREW 21472−139 −−− 4
54 −SPACER 31144−034 15210 1
55 −BALL BEARING 23251−019 −−− 1
56 −OIL SEAL 25228−648 −−− 1
57 −PLUG W/FIB WASHER 22638−001 −−− 1
58 −OUTPUT SHAFT 38521−716 16000 1
59 −BEARING CAP 38325−013 10000 1
60 −BUSHING 24571−109 −−− 1
61 HEX HD CAPSCREW 21472−139 −−− 4
62 BRG CAP GASKET 38687−548 19060 1
72 D WASHER 31133−131 18010 2
73 D PROTECTIVE CAP 25141−251 −−− 2
74 D WASHER 31133−131 18010 1
75 D TUBING .500 FT 18523−502 −−− 1
76 D PROTECTIVE COVER 31133−224 18010 1
NOT SHOWN:
D PROTECTIVE CAP 25141−261 −−− 2
GEAR LUBE DECAL 38816−086 −−− 1
LK PLATE WASHER 31215−042 15000 2
HEX HD CAPSCREW 22434−552 −−− 4
D NOTE: ITEMS ARE PROVIDED FOR SHIPPING PURPOSES ONLY. THESE PARTS MUST BE REMOVED BEFORE INSTALLATION.
INDICATES PARTS RECOMMENDED FOR STOCK
