ProTeam Sierra - Manual (Page 20)

18 – ProTeam Owner's Manual / Manual del propietario de ProTeam / Mode d’emploi ProTeam
1
2
4
3
7
5
13
5
23
22
17
27
19
6
21
20
8
9
9
10
11
24
26
18
25
16
15
15
12
8a
14
28
No. Product Name Qty
1 103318 Top Cap, Black 1 ea.
2 104544 698 Sq. In. Intercept Micro Filter 10/pk
3 103115 Micro Cloth Filter 1 ea.
4 103327 On/Off Switch 1 ea.
5 103212 Wire Harness Assembly: 3 Wires and Strain Relief 1 set
6 106110 Gasket 1 ea.
7 105047 Receptacle Assembly for Powerhead 1 ea.
8 103236 Motor Seal 1 ea.
8a 105430 Upper Foam Compression Ring 1 ea.
9 102784 Dome Filter w/Filter Media 1 ea.
10 101949 Replacement Foam Media for Dome Filter 1 ea.
102761 High Filtration Disk (Optional) 2/pk
11 105687 Motor/Fan (120V) 1 ea.
12 105164 Carbon Brush Set (Domel Motor) 1 set
101720 Carbon Brush Set (Ametek Motor) 1 set
13 103121 Motor Mount 1 ea.
14 103117 Tool Dock 1 ea.
15 103266 Motor Mount and Vented Exhaust Cover Screw Kit 1 set
16 103215 Power Cord (18" 14/3) Assembly w/Locknut and Washer 1 ea.
17 103123 Exhaust Foam 1 ea.
18 103360 Cover Assembly, Vented Exhaust 1 ea.
19 103256 Rear Foam Diffuser 1 ea.
103124 Foam Inlet Damper A (not shown) 1 ea.
103125 Foam Inlet Damper B (not shown) 1 ea.
20 103267 Rear Wheel Assembly Kit: 2 Wheels, 2 Spacers, 2 Screws 1 set
21 103268 Rear Wheel Mounting Screw Kit: 2 Screws 1 set
22 103114 Swivel Caster (Front Wheel) 1 ea.
23 103545 Conical Washer for Swivel Caster 1 set
24 103172 78" Static Dissipating Hose w/Cuffs (Black) 1½" 1 set
25 100694 Replacement Swivel Cuff (Black) 1½" 1 ea.
26 103150 Replacement Long Swivel Cuff (Black) 1½" 1 ea.
27 103476 Thermal Protector 1 ea.
28 103441 Cord Lock 1 ea.
101678 50' Extension Cord (Not Shown) 1 ea.
ProVac CN Assembly
PROVAC CN PARTS LIST
