19
SPARE PARTS KIT (N1 AND N3 CONSTRUCTION) MODELS 500 THROUGH 547
FIG.
NO.
DESCRIPTION
QTY.
PART
NUMBER
539 Discharge Valve Cartridge 1 000209
544 Suction Valve Cartridge 1 000217
549 Valve Seat O-Ring 4 100204
538 Valve Cap O-Ring 4 100200
533 Diaphragm (Models 500 & 501 Only) 1 000231
533 Diaphragm (All Other Models) 1 000200
517 Control Rod O-Ring 2 100188
516 Sealing Plate O-Ring (Models 500/501/510/515) 2 100184
516 Sealing Plate O-Ring (Models 520/522/525/527) 2 100185
516 Sealing Plate O-Ring (Models 530/532/535/537/538) 2 100186
516 Sealing Plate O-Ring (Models 547) 2 100244
KIT NUMBER 002712
DUPLEX PUMPS
REQUIRE 2 KITS
SPARE PARTS KIT (N4 CONSTRUCTION) MODELS 500 THROUGH 547
FIG.
NO.
DESCRIPTION
QTY.
PART
NUMBER
539 Discharge Valve Cartridge 1 000210
544 Suction Valve Cartridge 1 000218
549 Valve Seat O-Ring 4 100204
538 Valve Cap O-Ring 4 100200
533 Diaphragm (Models 500 & 501 Only) 1 000231
533 Diaphragm (All Other Models) 1 000200
517 Control Rod O-Ring 2 100188
516 Sealing Plate O-Ring (Models 500/501/510/515) 2 100184
516 Sealing Plate O-Ring (Models 520/522/525/527) 2 100185
516 Sealing Plate O-Ring (Models 530/532/535/537/538) 2 100186
516 Sealing Plate O-Ring (Models 547) 2 100244
KIT NUMBER 002713
DUPLEX PUMPS
REQUIRE 2 KITS
SPARE PARTS KIT (N5 CONSTRUCTION) MODELS 500 THROUGH 547
FIG.
NO.
DESCRIPTION
QTY.
PART
NUMBER
P-539-C Discharge Valve Cartridge 1 000259
P-544-C Suction Valve Cartridge 1 000262
P-549-C Valve Seat O-Ring 4 100185
P-538-C Valve Cap O-Ring 4 100244
533 Diaphragm (Models 500 & 501 Only) 1 000231
533 Diaphragm (All Other Models) 1 000200
517 Control Rod O-Ring 2 100188
516 Sealing Plate O-Ring (Models 500/501/510/515) 2 100184
516 Sealing Plate O-Ring (Models 520/522/525/527) 2 100185
516 Sealing Plate O-Ring (Models 530/532/535/537/538) 2 100186
516 Sealing Plate O-Ring (Models 547) 2 100244
KIT NUMBER 002714
DUPLEX PUMPS
REQUIRE 2 KITS
