Preliminar y, Wmk 150 • setup guide, cont'd – Extron Electronics WMK 150 User Manual
Page 6
PRELIMINAR
Y
WMK 150 • Setup Guide, cont'd
6
Extron Headquarters
+1.800.633.9876 (Inside USA/Canada Only)
Extron Asia
+65.6383.4400
Extron China
+86.21.3760.1568)
Extron Korea
+82.2.3444.1571
Extron Europe
+31.33.453.4040
Extron Japan
+81.3.3511.7655
Extron Middle East
+971.4.2991800
Extron India
+91.80.3055.3777
© 2012 Extron Electronics — All rights reserved. All trademarks mentioned are the property of their respective owners.
www.extron.com
2.75"
(6.99 cm)
15.50"
(39.37 cm)
13.00"
(33.02 cm)
Top View
Cover Front View
Side View
Both
Sides
15.37"
(39.04 cm)
12.87"
(32.69 cm)
Both Sides
Both
Sides
Base Plate Front View
2.00"
(5.08 cm)
