TSC 100 • Specifications, Part Numbers, and Accessories
Specifications, Part Numbers, Accessories, cont’d
A-4
Parts
Included Parts
These items are included in each order for a TSC 100:
Included parts
Replacement part number
TSC 100
60-451-01
9 VDC, 1A external power supply
70-056-01
TSC 100 User’s Manual
Accessories
Accessories
Part number
Through-desk mounting bracket kit
70-077-02
19” 1U Universal Rack Shelf
60-190-01
Cables
Cables
Part number
S-video cable, up to 100’ (various lengths)
26-316-xx
Superflex SHR cable, BNC (various lengths)
26-383-xx
RS-232 cable, male-to-female (var. lengths)
26-433-xx
Adapters
Adapters
Part number
Male S-video to 2 female BNCs, 8”
26-353-01
Male S-video to 2 male BNCs (var. lengths)
26-353-xx
Female S-video to 2 female BNCs, 8”
26-541-01
Female S-video to 2 male BNCs (var. lengths) 26-541-xx
