Extron Electronics TSC 100 User Guide User Manual
Page 15
TSC 100 • Serial Control
Serial Control, cont’d
TSC 100
A
Appendix A
Specifications, Part Numbers,
and Accessories
Specifications
Parts
3-10
2
.
Click on the comm port that is
connected to the interface’s RS-232
port. The control software will “look
for” the interface at that port and read
its configuration.
The control program window (shown
below) will appear and display
current settings.
Figure 8 — Control program window
Using the help system
For information on program features, press
the F1 computer key or click on the Help
menu from within the control program, or
double-click on the TSC 100 Help icon in the
Extron Electronics group or folder.
