Table of Contents
Chapter One • Introduction .................................................... 1-1
About this Manual ..................................................................... 1-2
About the MTPX Plus Switchers ............................................ 1-2
Twisted Pair (TP) Cable Transmission Distance ................. 1-4
TP Skew Equalization ................................................................ 1-5
Chapter Two • Installation ....................................................... 2-1
Rear Panel ..................................................................................... 2-2
Inputs....................................................................................... 2-3
RS-232 output inserts............................................................. 2-4
Outputs.................................................................................... 2-4
Remote control........................................................................ 2-5
Power....................................................................................... 2-6
Front Panel .................................................................................... 2-6
Chapter Three • Front Panel Operation .......................... 3-1
Creating a Tie ............................................................................... 3-2
Saving or Recalling a Preset .................................................... 3-3
Setting the Front Panel Locks (Executive Modes) ............ 3-4
Selecting Lock mode 2 or toggling between
mode 2 and mode 0................................................................ 3-4
Selecting Lock mode 2 or toggling between
mode 2 and mode 1................................................................ 3-5
Defining the Audio/RS-232 Wire Pair
and Configuring the Remote Port
..........................................3-6
Viewing and Adjusting the Audio Level ............................. 3-7
Viewing Ties and Muting Outputs ....................................... 3-8
Video Adjustments ..................................................................... 3-8
Chapter Four • Remote Control and
Optimizing the Video ................................................................... 4-1
Selected SIS ™ Commands ......................................................... 4-2
Establishing a network (Ethernet) connection..................... 4-2
Connection timeouts...............................................................4-2
Number of connections...........................................................4-3
Verbose mode..........................................................................4-3
Establishing a USB port connection....................................... 4-3
Host-to-switcher instructions................................................. 4-3
Command/response table for selected SIS commands........ 4-4
i MTPX Plus Series • Table of Contents
