Refer also to the MTPX Plus User’s Manual at www.extron.com .
3 . Increase/decrease the level or volume by pressing the
Esc ( > ) and View ( < ) buttons.
ESC VIEW
button decreases
the level or volume. button increases
the level or volume.
4 . Press and release the Audio button to exit.
Viewing Ties and Muting Outputs
1 . Press the View button. Output buttons light for outputs
that have no ties established.
N If an output button blinks, that output is muted. To
toggle mute on and off, press and hold the output button
for 2 seconds.
2 . Press an input button. The buttons for all tied outputs
light (amber for video and audio, green for video only, and
red for audio only).
3 . Press an output button. The buttons for the tied input and
all tied outputs light.
4 . Press the View button. All input and output buttons return
to an unlit state.
Video Adjustments
Image adjustments are available via SIS commands, the
Windows-based control and configuration program, and the
built-in HTML pages. See chapter 4, “ Remote Control and
Optimizing the Video ”.
