Cables/connectors
N
Enhanced Skew-Free™ A/V UTP cables are not
recommended for Ethernet/LAN applications.
Enhanced Skew-Free™ A/V cable
Part number
Enhanced Skew‑Free A/V UTP Cable
(various lengths)
26‑569‑xx
Enhanced Skew‑Free A/V UTP, 1000' bulk
22‑141‑03
Plenum Enhanced Skew‑Free A/V UTP,
1000' bulk
22‑142‑03
RJ-45 connector
Part number
CAT 6 jack (black)
100‑476‑01
CAT 6 jack (red)
100‑477‑01
CAT 6 jack (blue)
100‑478‑01
CAT 6 jack (orange)
100‑479‑01
CAT 6 jack (gray)
100‑480‑01
CAT 6 jack (white)
100‑481‑01
CAT 6 jack (ivory)
100‑482‑01
S-video to BNC adapter
S‑video male to 2 female BNC (8"/0.2 m)
26‑353‑01
S‑video male to 2 male BNC (1’/0.3 m)
26‑353‑02
Skew compensation solutions
Skew equalizer
SEQ 100 15HD
60‑676‑01
