2.9"

(7.4 cm)

12.9"

(32.77 cm)

SURFACE CUT-OUT

AREA FOR

FURNITURE MOUNT

MLM 206 7GWP

13.57"

(34.46 cm)

Cut-Out Template for Extron's MLM 206 7GWP

TEMPLATE IS NOT FULL SIZE.

To install MLC 206
and MLM 206 7GWP
directly into furniture,
cut along this line.

Top Panel

Location of MLC 206

4.5"

(11.4 cm)

4
