Extron Electronics MLM 206 7GWP User Manual
Page 3
3
MediaLink
™
Mounting Options • Installation Guide
.250" (1.00 cm)
2.9"
(7.4 cm)
8.9"
(22.6 cm)
SURFACE CUT-OUT
AREA FOR
FURNITURE MOUNT
10"
(25.4 cm)
Cut-Out Template for Extron's MLM 206 LAAP
TEMPLATE IS NOT FULL SIZE.
To install MLC 206
and MLM 206 LAAP
directly into furniture,
cut along this line.
Top Panel
Location of MLC 226
3.15"
(8.0 cm)
.295" (1.16 cm)
