Installation, cont’d – Extron Electronics ISS 506 IO_board Installation User Manual
Page 7
Installation, cont’d
ISS 506 Optional I/O board • Installation
2
.
On the main board (figure 2), locate connectors J26, J43, and J44 (
a
); the three standoffs (
b
); and the
rear panel connector port (
c
).
J44
J43
J26
1
2
3
2
2
1
1
Figure 2 — SDI/HD-SDI input board installation location
3
.
From the inside of the switcher, pop the cover out of the rear panel connector port (
c
).
