Installation
and Operation
This section provides information on:
z z Installation Overview
z z
Front Panel Features
z z Transmitter Rear Panel Features
z z Receiver Rear Panel Features
z z
Power Supply Wiring
z z Twisted Pair Cable Termination
z z Skew Delay Compensation
Installation Overview
Follow the steps below to properly install and operate any of the Extron MTP 15HD A
transmitters and receivers.
CAUTION: Do not connect these devices to a computer data or telecommunications
network.
1. Turn off all MTPs and devices. Make sure that the input sources, the MTP, and
the output sources are all turned off and all power sources and signal cables are
disconnected.
2. If applicable, mount the MTPs (see " Mounting " on page 20).
3. Connect the transmitter inputs (see " Transmitter Rear Panel Features " on page 8).
4. Connect twisted pair (TP) cables between the MTP units (see " Transmitter Rear Panel
Features " on page 8 and " Receiver Rear Panel Features " on page 10).
5. Connect the receiver outputs (see " Receiver Rear Panel Features " on page 10).
6. Configure the receiver DIP switches (see " Receiver Rear Panel Features " on page 10).
7. Connect the power supply and turn on all devices (see " Power Supply Wiring " on
page 13).
8. Adjust the level and peaking (see " Front Panel Features " on page 6).
9. Adjust the skew delay control (see " Front Panel Features " on page 6).
MTP 15HD A Series • Installation and Operation 5
