Maximum resolution ..................... Up to 1920x1200 or 2048x1080 or 1080p at 300'
Up to 1024x768 at 600'
NOTE: Refer to the user guide for the maximum distances recommended for specific resolutions.
Sync
Input type (transmitters) ................ RGBHV, RGBS, RGsB, RsGsBs
Output type (receivers) .................. RGBHV, RGBS, RGsB, RsGsBs
Standards ..................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Input level (transmitter) ................. 3.5 V to 5.5 Vp-p, unterminated
Output level (receivers) .................. 4.0 V to 5.0 Vp-p, unterminated
Input impedance (transmitter) ....... 573 ohms ±5%
Output impedance (receivers) ........ 110 ohms
Max. input voltage (transmitter) .... 5.5 V p-p
Polarity
Transmitter ................................ Positive or negative (follows input polarity)
Receivers ................................... Positive or negative (switch-selectable)
Audio
Number/signal type ....................... 1 set of proprietary analog signals
Connectors ................................... 1 female RJ-45
Gain ............................................. Unbalanced output: 0 dB; balanced output: +6 dB
Frequency response....................... 20 Hz to 20 kHz, ±1 dB
THD + Noise ................................. 0.15% @ 1 kHz, 0.3% @ 20 kHz at nominal level
S/N ............................................... >70 dB at maximum output (unweighted)
Stereo channel separation ............. >60 dB @ 1 kHz
CMRR ........................................... >43 dB @ 20 Hz to 20 kHz
Audio input — transmitters
Number/signal type ....................... 1 stereo, unbalanced
Connectors ................................... (1) 3.5 mm mini stereo jack
Impedance .................................... >10k ohms, unbalanced
Nominal level ................................ +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................. +18 dBu, (unbalanced) at 1%THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio output — receivers
Number/signal type ....................... 2 mono, balanced/unbalanced
Connectors ................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ..................................... ±1 dB channel to channel
Nominal level ................................ +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................. +18 dBu, unbalanced at 1% THD+N
General
Recommended cable type
C7 models ................................. Extron STP201 or CAT 7
All other models ........................ CAT 5/5e/6 (shielded or unshielded)
Power supply ................................ External
Input: 100-240 VAC, 50-60 Hz
Output: 12 VDC, 1 A, 12 watts
Power input requirements ............. 12 VDC, 0.5 A
MTP 15HD A Series • Reference Information 17
