3-7 IN1502 • Serial Communication
The syntax for setting a special function is X? * X! # where X? is the function number and X! is the
value. To view a function’s setting, use X? # where X? is the function number. In the following table the
values of the X? variable are different for each command/function. These values are given in the
rightmost column.
Command/response table for special function SIS commands
Command ASCII Command Response
X!
values
(host to scaler) (scaler to host) and additional descriptions
PAL file mode (2:2 pulldown detction)
Set mode on 18*1# PDn1 Set PAL file mode on.
Set mode off 18*0# PDn0 Set PAL file mode off.
View file mode status 18# PDn X2 Show PAL file mode status.
Blue mode
Set Blue mode on 8*1# Blu1 Set Blue mode on.
Set Blue mode off 8*0# Blu0 Set Blue mode off.
View Blue mode status 8 # Blu X2 Show Blue mode status.
Auto switch
Set Auto switch mode on 10*1# Aut1 Set Auto switch mode on.
Set Auto switch mode off 10*0# Aut0 Set Auto switch mode off.
View Auto switch mode status 10# Aut X2 Show Auto switch mode
status.
H Format (sync output format)
Set to horizontal sync 15*1# HFm0 Set H format to off/0
(horizontal sync, default).
Set to composite sync 15*0# HFm1 Set H format to on/1
(composite sync).
View H Format status 15# HFm X2 Show H format mode status.
