Extron • Matrix 100 • User’s Manual
Appendix B • Part Numbers and Reference
BNC-4 Cables (High Resolution BNC Cables)
Extron BNC-4 cables are high resolution (HR) BNC cables, color coded with
solid colors and wrapped in a single jacket. The total cable diameter is 0.398".
Extron recommends that when using signals with a scanning frequency of 15-
125 kHz and running distances of 100 feet or more, high resolution BNC cables
should be used to achieve maximum performance. The following cables are
stock lengths:
Cable -Length Part #
BNC-4-3' HR ................ 26-210-01
BNC-4-6' HR ................ 26-210-02
BNC-4-12' HR .............. 26-210-03
BNC-4-25' HR .............. 26-210-04
BNC-4-50' HR .............. 26-210-05
BNC-4-75' HR .............. 26-210-06
BNC-4-100' HR ............ 26-210-07
BNC-4-150' HR ............ 26-210-08
BNC-4-200' HR ............ 26-210-09
BNC-4-300' HR ............ 26-210-53
BNC-4-500' HR ............ Bulk Length
BNC-4-1000' HR .......... Bulk Length
_______ Bulk cable in lengths up to 5000' rolls is available with or without connectors.
BNC Cable Specifications
Conductors .................. Silver Plated Alloy
Insulation ..................... Foam Polypropylene
Nominal Outer Dimension
0.398"
DC Resistance ............. 41.5 Ohms/1000 ft.
Impedance ................... 75.5 Ohms, Nominal
Time Delay .................. 1.28 Nanoseconds/ft.
Capacitance ................. 17 pF/ft.
BNC-5 HR Cables
High resolution 5 conductor BNC cables include cables for Red, Green, Blue,
Horizontal and Vertical Sync. These cables are required when using the
Matrix 100 with separate horizontal and vertical sync inputs and outputs. The
specifications are the same for the BNC-5 HR and BNC-4 HR cables.
B-2
