Extron • Matrix 100 • User’s Manual
Appendix B • Part Numbers and Reference
B-1
Related Part Numbers
Extron Part Part #
Blank Front Panel 60-147-01
Front Panel Controller (QS-FPC) 60-188-01
Audio Connectors (Phoenix) 10-163-01
SVHS-to-BNC Adapter 26-353-01
GLI 250 60-123-01
- (Ground Loop Isolator, 250 MHz RGBHV)
PA 250
60-124-01
- (Peaking Amplifier, 200 MHz RGBS)
Matrix 100 User's Manual
68-199-01 - (this manual)
SC 110 Sync Combiner (115v) 60-153-01 (230v = 60-153-02
SC 210 Sync Processor (115v) 60-154-01 (230v = 60-154-02)
Option Kit Part Numbers
Kits can be ordered from Extron for adding modules to an existing Matrix 100.
The following list gives part numbers for available kits.
Matrix 100 Option Kit Part #
Redundant Power Supply 70-020-01
8 x 8 Stereo Audio Module 70-039-01
4 x 4 MRAM (for RGB) 70-041-01
8 x 4 MRAM (for RGB) 70-041-02
8 x 8 MRAM (for RGB) 70-041-03
4 x 4 Sync Module 70-024-01
8 x 4 Sync Module 70-024-02
8 x 8 Sync Module 70-024-03
4 x 4 Composite Video 70-025-01
8 x 4 Composite Video 70-025-02
8 x 8 Composite Video 70-025-03
These kits include all the necessary parts, as well as instructions for a qualified
person to add options to a Matrix 100. Chapter 2 of this manual also has some
procedures for adding options.
