Operation, cont’d
Matrix 50 Series Switchers • Operation
3-18
Worksheet example 3: Test configuration
The A/V system in this fictional organization needs to be fine tuned on a regular
basis. Figure 3-18 shows a typical test configuration, with an Extron video test
generator (input 12) generating a test pattern to all monitors (outputs 1, 2, 3, 4, and
6). Sound checks are run from the CD player (input 5) to all audio systems
(outputs 3, 4, 6, and 8).
Test configuration
Input sources
Camera
main
podium
Main
hall
monitor
Fill in the preset number, use colors or dashes, etc. to make connecting lines.
Indicate if the configuration is for Video, Audio, or both.
Preset #
Title:
Video:
Audio:
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
12
Main
podium
monitor
Lunch
room
stereo
Class
room #1
rear proj
Archive
VCR
Lobby
monitor
12
Class
room #2
rear proj
Security
camera
#2
Lobby
security
camera
Podium
mic
Audio
CD
Class
room #1
VCR
Class
room #2
VCR
Class
room #1
LD
Class
room #2
LD
VTG
200
Output destinations
Figure 3-18 — Worksheet example 3: Test configuration
