68-2260-01 Rev. C
12 13
Extron Headquarters
+800.633.9876 Inside USA/Canada Only
Extron USA - West
Extron USA - East
+1.714.491.1500 +1.919. 850.1000
+1.714.491.1517 FAX +1.919. 850.1001 FAX
Extron Europe
+800.3987.6673
Inside Europe Only
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+65.6383.4400
+65.6383.4664 FAX Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX Extron China
+86.21.3760.1568
+86.21.3760.1566 FAX Extron Middle East
+971.4.299.1800
+971.4.299.1880 FAX Extron Korea
+82.2.3444.1571
+82.2.3444.1575 FAX Extron India
1800.3070.3777
(Inside India Only)
+91.80.3055.3777
+91.80.3055.3737 FAX
© 2013 Extron Electronics All rights reserved. All trademarks mentioned are the property of their respective owners. www.extron.com
HFX 100 Tx and HFX 100 Rx • User Guide
Mounting
Desktop Placement
Attach the four provided rubber feet to the bottom of the HFX 100 transmitter or receiver and place it in any convenient location.
Rack Mounting
UL guidelines for rack mounting
The following Underwriters Laboratories (UL) guidelines are relevant to the safe installation of these products in a rack:
Elevated operating ambient temperature — If the units are installed in a closed or multi-unit rack assembly, the operating
ambient temperature of the rack environment may be greater than room ambient temperature. Therefore, install the equipment in an
environment compatible with the maximum ambient temperature (Tma: +122 °F, +50 °C) specified by Extron.
Reduced air flow — Install the equipment in the rack so that the equipment gets adequate air flow for safe operation.
Mechanical loading — Mount the equipment in the rack so that uneven mechanical loading does not create a hazardous condition.
Circuit overloading — Connect the equipment to the supply circuit and consider the effect that circuit overloading might have on
overcurrent protection and supply wiring. Consider the equipment nameplate ratings when addressing this concern.
Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted equipment. Pay particular attention to supply
connections other than direct connections to the branch circuit (such as the use of power strips).
Rack mounting procedure
To mount the unit on a rack shelf, follow the instructions provided with the shelf accessories.
