HFX 100 Tx and HFX 100 Rx • User Guide
Application Diagram
POWER
12V
- - A MAX
OUTPUT
INPUT
HFX 100 Tx
POWER
12V
- - A MAX
HFX 100 Rx
INPUT
OUTPUT
STANDBY/ON
PQ
LS
HD
MI
OPEN/CLOSE
FL OF
F
US
B
Extron
HFX 100 Tx
Transmitter
Extron
HFX 100 Rx
Receiver
Blu-ray Player
HDMI
HDMI
Flat Panel Display
Up to 300m ( 984 ft )
on Multimode Fiber
Figure 1.
Typical HFX 100 Application
Product Label
DFX/HFX 100 Series
33-2458-02
Rev. A
www.extron.com
About
Extron Electronics
1025 East Ball Road
Anaheim, CA 92805
Class 1 Laser Product
21.CFR 1040.10
This label is affixed to the bottom of the unit.
