Command ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
Device name
NOTE: No blank or space characters are permitted. The first character must be a letter. The last character
cannot be a minus or hyphen.
Set unit name EX1^
CN
}
Ipn •X1^] Set device name.
Set unit name to factory
default E•
CN
}
Ipn •X1&] Set device to default.
View unit name E CN } X1^] View device name.
Information requests
Query general information I 1Lnk X%• 2Lnk X%• Vid X%• Aud X%•X1)• TX ]
Query firmware version Q x.xx ]
Query firmware build *Q x.xx.xxxx
]
Query part number N 60-1229-nn
]
Query all firmware version 0Q x.xx-x.xx
]
Query updated FPGA version 35Q x.xx
]
Status request
View fiber link 1 status 1S X%]
View fiber link 2 status 2S X%]
View input video status 3S X%X%X%]
View input audio status 4S X%]
Request all signal status 5S SigI
X%X%X%•
SigO- • 2HdcpI
X%•
3HdcpI
X%•
HdcpO-
]
Request HDMI signal status 6S SigI
X%X%•
SigO-
]
Request HDCP status 7S 2HdcpI
X%•
3HdcpI
X%•
HdcpO-
]
NOTE: X% = On or off 0 = off or not detected
1 = on or detected
X1) = SFP module type SM = singlemode
MM = multimode
X1! = Input selection 1 = VGA (input 1)
2 = HDMI (input 2)
3 = HDMI (input 3)
X1^ = Unit name text string up to 24 characters ( A - Z , 0 - 9 , - ). No blank
or space characters are permitted. The first character
must be a letter. The last character cannot be a hyphen.
X1& = Extron device name FOX-T-USW-103
FOX T USW 103 Universal Switcher • Remote Control 18
