Command

ASCII Command

(Host to Device)

Response

(Device to Host)

Additional Description

Picture Adjustment (Analog Only)

Pixel phase

Set a pixel phase value

E

1*

X2@

PHAS

}

Phas

X2@]

Adjust the pixel phase to

X2@

.

Increment value

E

1+PHAS

}

Phas

X2@]

Increase the pixel phase.

Decrement value

E

1-PHAS

}

Phas

X2@]

Decrease the pixel phase

View pixel phase value

E

1PHAS

}

X2@]

Show the pixel phase value

Total pixels

Set a value

E

1*

X2#

TPIX

}

Tpix

X2#]

Set the total pixels.

Increment value

E

1+TPIX

}

Tpix

X2#]

Increase the total pixels.

Decrement value

E

1-TPIX

}

Tpix

X2#]

Decrease the total pixels.

View total pixel value

E

1TPIX

}

X2#]

Show the total pixels.

Horizontal start

Set horizontal start value

E

1*

X2$

HSRT

}

Hsrt

X2$]

Set horizontal location of first
active pixel in active window.

Increment value

E

1+HSRT

}

Hsrt

X2$]

Move the image to the right.

Decrement value

E

1-HSRT

}

Hsrt

X2$]

Move the image to the left.

View horizontal start value

E

1HSRT

}

X2$]

Show horizontal location of the
first active pixel in active window.

EDID

NOTE: Digital EDID can be assigned only to a digital input. Analog EDID can be assigned only to an analog

input.

Input EDID (VGA and HDMI)

Assign factory EDID

E

A

X1!

*

X2^

EDID

}

EdidA

X1!

*

X2^]

Set the EDID resolution and
refresh for input

X1!

.

View assigned EDID

E

A

X1!

EDID

}

X2^]

View EDID resolution and refresh
for input

X1!

.

View EDID native resolution

E

N

X1!

EDID

}

X@]

View current EDID in Hex

E

R

X1!

EDID

}

X#]

Export EDID selection

E

E

X2^

EDID

}

X$]

Export EDID in binary format.

Import EDID to store
location

E

I

X1$

EDID

}X$

EdidI

X1$]

Import EDID in binary format to
user stored EDID slot

X1$

.

NOTE:

X@

= Native resolution and refresh rate

X#

= EDID record (Hex)

128 or 256 bytes

X$

= EDID record (binary)

128 or 256 bytes

X1!

= Input selection

1

= VGA (input 1)

2

= HDMI (input 2)

3

= HDMI (input 3)

X1$

= User assigned EDID

55

= VGA (input 1)

56

= HDMI (input 2)

57

= HDMI (input 3)

X2@

= Pixel phase

0

to

63

(

32

= default)

X2#

= Total pixels

±

255

of the default value (depends on the input rate)

X2$

= Horizontal start

0

to

255

(

128

= default)

X2^

= EDID output resolution

See the tables on page 13.

FOX T USW 103 Universal Switcher • Remote Control

16
