Extron Electronics FOX Matrix 14400 Setup Guide User Manual
Page 13
Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Channel mute commands
Channel.mute
X@
*1B
Vmt
X@
*1
]
Mute.output.
X@
.(no.signal.is.output,.but.the.
light.output.remains.active).
Channel.unmute
X@
*0B
Vmt
X@
*0
]
Unmute.output.
X@
.(signal.is.output).
Read.channel.mute
X@
B
X#]
1.=.mute.on,.0.=.mute.off.
Global.channel.mute
1*B
Vmt1
]
Mute.all.light.outputs.
Global.channel.unmute
0*B
Vmt0
]
Unmute.all.light.outputs.
View.output.mutes
E
VM
}
X#
1
X#
2
.....
X#
n
]
Each.
X#
.response.is.the.mute.status.of.an.
output,.starting.from.output.1..
n.=.the.maximum.number.of.outputs.for.your.
configuration.
Save and recall presets
NOTE:. If.you.try.to.recall.a.preset.that.is.not.saved,.the.matrix.switcher.responds.with.the.error.code.E11.
Save.current.configuration.as.a.
global.preset
X$
,
Spr
X$]
Command.character.is.a.comma.
Example:
9,
Spr09
]
Save.current.ties.as.preset.9.
Recall.a.global.preset
X$
.
Rpr
X$]
Command.character.is.a.period.
Example:
5.
Rpr05
]
Recall.preset.5,.which.becomes.the.current.
configuration.
NOTE:.
X@
.=.Output.number.
.
01.–.(maximum.number.of.outputs.for.your.model)
X#
.=.Mute.
.
.
0.=.not.muted,.1.=.muted
X$
.=.Global.preset.#.
.
01.-.64
Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Information requests
Information.request
I
V
X%
X
X^
•A
X%
X
X^
•S
X&
1
X&
2
...
X&
n
]
V
X%
X
X^
.shows.the.number.of.available.inputs.
and.outputs.for.this.configuration..
A
X%
X
X^
.has.no.meaning.for.this.product.
S
X&
1
X&
2
...
X&
n
.shows.the.board.type.installed.
in.each.slot..n.is.9.(FOX.Matrix.14400).or.
20.(FOX.Matrix.320x).
Request.part.number
Request.part.number.and.Board.
configuration
N
X*]
*N
X*
.
X&
1
X&
2
X&
3
X&
4
X&
5
X&
6
X&
7
X&
8
X&
n
]
n.is.9.(FOX.Matrix.14400).or.
20.(FOX.Matrix.320x).
Query.controller.firmware.
version
Q
X(]
Example:
Q
1.23
]
The.factory-installed.controller.firmware.
version.is.1.23.(sample.value.only).
NOTE:.
X%
.=.Inputs.
.
Total.number.of.inputs.for.this.switcher
X^
.=.Outputs.
.
Total.number.of.outputs.for.this.switcher
X&
.=.Board.installed.
0.=.No.board.installed
. .
.
.
1.=.16x16.multimode.board.
. .
.
.
2.=.16x16.singlemode.board.
. .
.
.
x.=.Unknown.board.or.mix.of.transceivers.installed.
X*
.=.Part.number.
60-nnnn-nn
X(
.=.Firmware.version.number.to.second.decimal.place.(x.xx)
