Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Create ties
NOTES: • Commands can be entered back-to-back in a string, with no spaces. For example: 1*1!02*02&003*003%.
• The matrix switchers support 1-, 2-, and 3-digit numeric entries (1*1!, 02*02&, or 003*003%).
• The ! tie command, the & tie command, and the % tie command can be used interchangeably.
• The ! read tie command, & read tie command, and the % read tie command can be used interchangeably.
Tie input
X!
to output
X@
X!
*
X@
!
Out
X@
•
In
X!
•
All
]
Tie input
X!
to output
X@
.
Example (see Note, above):
1*3!
Out003•In001•All
]
Tie input 1 to output 3.
Tie input
X!
to output
X@
X!
*
X@
&
Out
X@
•
In
X!
•
RGB
]
Tie input
X!
to output
X@
.
Example (see Note, above):
10*4&
Out004•In010•RGB
]
Tie input 10 to output 4.
Tie input
X!
to output
X@
X!
*
X@
%
Out
X@
•
In
X!
•
Vid
]
Tie input
X!
to output
X@
Example (see Note, above):
7*5%
Out005•In007•Vid
]
Tie input 7 to output 5.
Read output tie
X@
&
X!]
Input
X!
is tied to output
X@
.
Read output tie
X@
%
X!]
Input
X!
is tied to output
X@
.
Read output tie
X@
!
X!]
Input
X!
is tied to output
X@
.
NOTE:
X!
= Input number
00 – (maximum number of inputs for your configuration) (00 = untied)
X@
= Output number
01 – (maximum number of outputs for your configuration)
15
