Symbol Definitions
Symbols (variables), defined below, are used in the command and response table. The
symbols represent variables in the command and response table fields.
]
= Carriage return and line feed
}
= Carriage return (no line feed)
•
= space
X!
= Output
1 through 8
X@
= Mute status
0 = off (unmuted)
1 = on (muted)
X#
= Reclockable input number
00 = all inputs
01 = input 1 (group A)
03 = input 3 (group B)
05 = input 5 (group C)
07 = input 7 (group D)
X$
= Input reclocker rate
00 = Bypass (no reclocking)
02 = 2.125 Gbps
01 = 1.25 Gbps
03 = 4.25 Gbps (default)
X%
= Name
Up to 24 alphanumeric characters, excluding spaces or blank characters. The
first character must be alphabetic and the last character cannot be a hyphen or
or minus sign.
X^
= Firmware version
Vx.xx
X&
= Transceiver module status
0 = no light input
1 = light input
X*
= Temperature
nnnF = whole degree Fahrenheit
X(
= Transceiver module status
0 = no module installed
2 = singlemode
1 = multimode
X1)
= DA configuration switch position
1 = 1x8 DA (Default)
2 = Two 1x4 DAs
3 = Four 1x2 DAs
Command and Response Table for SIS Commands
Command Function
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Mutes
NOTE
:
The channel mute commands mute the data on the output only. The output continues to emit light
.
Mute output
X!
*1B
Vmt
X!
*1
]
Blank data on optical output
X!
.
Unmute output
X!
*0B
Vmt
X!
*0
]
Output data on optical output
X!
.
Show video mute status
X!
B
X@]
Output
X!
data output mute status is
X@
.
Mute all outputs
1*B
Vmt1
]
Blank data on all optical outputs.
Unmute all outputs
0*B
Vmt0
]
Output data on all optical outputs.
Show mute status of all outputs
E
VM
}
X@
1
X@
2
X@
3
X@
4
...
X@
8
]
Show output 1 through output 8 mute
status.
Reclocking
Set reclocker mode
X#
*
X$
=
Rte
X#
*
X$]
Set the reclocker mode for input
X#
to
X$
.
Example 1:
0*0=
Rte00*00
]
Set the reclocker mode for all inputs to
bypass (do not reclock).
Example 2:
5*2=
Rte05*02
]
Set the reclocker mode for input 5
(group C) to 2.125 Gbps.
Show reclocker mode
X#
=
X$]
Device naming
Set device name
EX%
CN
}
Ipn•
X%]
Set the name of the DA to
X%
.
Example:
E
Active_DA_1CN
}
Ipn•Active_DA_1
]
Name the unit “Active_DA_1.”
Set device to factory default name
E
•CN
}
Ipn•FOX-DA8-Plus]
View device name
E
CN
}
X%]
The device name is
X%
.
Information Requests
Information request
I
V01X08•A00X00
]
V01X08 shows the number of available
inputs (1) and outputs (8) for this
product. A00X00 has no meaning for
this product.
Show firmware version
Q
X^]
Example:
Q
1.23
]
The factory-installed controller firmware
version is 1.23 (sample value only).
