Control Modules • Specs, Part Numbers, and Accessories A-2
Specifications
General
Power input requirements .......... 12 VDC, 0.08 A (CM-9BLB fully lit);
12 VDC, 0.026 A (CM-3BLB , fully lit),
from an Extron MediaLink
™ controller,
System 5 IP, or external power supply
All other models ............................ 12 VDC, 0.020 A from an Extron
MedialinkController (MLC), MediaLink
Switcher (MLS) or System 5 IP Switcher.
Temperature/humidity ................ Storage: -40 to +158 ° F (-40 to +70 ° C) /
10% to 90%, non condensing
Operating: +32 to +122 ° F (0 to +50 ° C) /
10% to 90%, non condensing
Rack mount .................................... Yes, with optional faceplate; and
furniture/wall mountable with optional
faceplates or AAP wall plates
Enclosure type ............................... Metal
Enclosure dimensions
IRCM-VCR, IRCM-DVD, IRCM-Tape, ACM-Tone, ACM-Level,
RCM-SC, RCM-SC LT, CM-5BB, CM-3BLB
Faceplate ..................... 1.4" H x 3.5" W x 0.1" D
(3.5 cm H x 8.9 cm W x 0.3 cm D)
(double space high AAP plate)
Boards ........................ 1.3" H x 2.6" W x 0.9" D
(3.3 cm H x 6.6 cm W x 2.3 cm D)
(Depth excludes buttons. Allow at least
2.1" (5.3 cm) depth in the wall/furniture.)
IRCM-DVD+,CM-20BB, CM-9BLB, CM-19AC
Faceplate ..................... 2.8" H x 3.5" W x 0.1" D
(7.1 cm H x 8.9 cm W x 0.3 cm D) (4 space
high AAP plate)
Boards ........................ 2.7" H x 2.6" W x 0.9" D
(6.9 cm H x 6.6 cm W x 2.3 cm D) (Depth
excludes buttons. Allow at least 2.1"
(5.3 cm) depth in the wall/furniture.)
Product weight
IRCM-VCR, IRCM-DVD, IRCM-Tape, ACM-Tone,
ACM-Level, RCM-SC, RCM-SC LT, CM-5BB, and
CM-3BLB ............................ 0.1 lb (<0.1 kg)
IRCM-DVD+, CM-20BB, CM-9BLB, and
CM-19AC ............................ 0.2 lbs (0.1 kg)
Specifications, Part Numbers, and Accessories
Control Modules • Specs, Part Numbers, and Accessories A-3
Listings............................................ UL, CUL as components of the MLC 206
Compliances ................................... CE, FCC Class A, VCCI, AS/NZS, ICES
as components of the MLC 206, MLC 226,
or System 5 IP
MTBF ............................................... 30,000 hours
Warranty ......................................... 3 years parts and labor
Specifications are subject to change without notice.
Included Parts
These items are included with each of the control modules:
Included parts Part number
3.5 mm, 5-pole captive screw connectors 10-319-10
IR Emitter (with IRCM modules only) 19-823-01
Inter-connect cable 27-431-01
Control Modules User’s Manual
Accessories
Check the Extron website (www.extron.com) for available
accessories.
Recommended Cables
Cable Type Part number
CTLP, (Plenum Comm link) 26-461-xx
Backlit Button Labels
Label Type Part number
Backlit Text Button Labels 33-954-01
Backlit Icon Button Labels 33-955-01
Backlit International Button Labels 33-956-01
