Extron Electronics CIA101 User Manual
Page 8
6
CIA101 Operation Manual - V1.3 01/03/01
©2001 - INLINE, Inc.
CIA101 FRONT PANEL CONNECTORS AND CONTROLS
Horizontal
Position
Control
Monitor
Emulation with
LED Indicator
Local
Monitor
Output
Power
Indicator
Video
Input
Stereo
Audio
Input
CIA101 REAR PANEL CONNECTORS AND CONTROLS
Dip
Switches
Video
Output
Connectors
Audio
Output
Connector
( Balanced or Unbalanced )
Power
Connector
Sharpness
Control
