Reference information, cont’d – Extron Electronics CIA114F5 User Manual
Page 17
CIA111 and CIA114 • Reference Information
Reference Information, cont’d
A-8
4.5"
(11.4 cm)
Cut-Out Template for Extron's
CIA114
TEMPLATE IS
NOT FULL SIZE.
To install CIA114
directly into furniture,
cut along this line.
Top Panel
2.1"
(5.3 cm)
3.0"
(7.6 cm)
SURFACE
CUT-OUT
AREA FOR
FURNITURE
MOUNT
2.75"
(7.0 cm)
Location of CIA114
