CIA111 and CIA114 • Reference Information
Reference Information, cont’d
CIA111 and CIA114 • Reference Information A-4 A-5
Rack mount
CIA111, CIA114 .................. No, but wall or furniture mountable
CIA111AM .......................... No, but Ackerman
® GB3 floor box
mountable
CIA114F5 ............................ No, but Steel City ® 665 floor box
mountable
CIA114AM .......................... No, but Ackerman ® GB2 floor box
mountable
Enclosure type ............................... Metal
Enclosure dimensions
CIA111 faceplate ............................ 4.5" H x 5.0" W x 0.1" D
(11.4 cm H x 12.7 cm W x 0.2 cm D)
(2 gang)
CIA114 faceplate ................ 4.5" H x 2.75" W x 0.1" D
(11.4 cm H x 7.0 cm W x 0.2 cm D) (1 gang)
CIA111AM faceplate ......... 2.75" H x 7.9" W x 1.25" D
(7.0 cm H x 20.1 cm W x 3.2 cm D)
CIA114F5 faceplate ........... 2.1" H x 5.75" W x 1.0" D
(5.3 cm H x 14.6 cm W x 2.5 cm D)
CIA114AM faceplate ......... 2.75" H x 6.2" W x 1.25" D
(7.0 cm H x 15.7 cm W x 3.2 cm D)
Device ................................. 2.8" H x 1.9" W x 1.5" D
(7.1 cm H x 4.8 cm W x 3.8 cm D)
(Depth excludes connectors.)
Product weight .............................. 0.7 lbs (0.3 kg)
Shipping weight ............................ 3 lbs (2 kg)
Vibration ......................................... ISTA 1A in carton
(International Safe Transit Association)
Listings............................................ ETL (UL1950)
Compliances ................................... CE
MTBF ............................................... 30,000 hours
Warranty ......................................... 3 years parts and labor
N All nominal levels are at ±10%.
N Specifications are subject to change without notice.
Part Numbers
CIA interface part numbers
Included parts Part numbers
CIA111 with cable guard (black, white) 60-596-12, -13
CIA111 without cable guard (black, white) 60-596-22, -23
CIA114 (black, white)
60-597-12, -13
CIA114F5 60-597-32
Included parts
CIA111
These items are included in each order for a CIA 111:
Included parts Part numbers
IEC power cord
9 VDC, 1A external power supply
28-070-01
Blank MAAP, single (black, white) (2) 70-315-11, 70-315-21
Blank MAAP, double (black, white) (1) 70-315-12, 70-315-22
1/4" round hex screws (8)
3/32" hex wrench
1/2" Phillips screws (4)
Tweeker (small screwdriver)
CIA111 and CIA114 User’s Manual
CIA114 or CIA114F5
These items are included in each order for a CIA 114 or
CIA114F5:
Included parts Part numbers
IEC power cord
9 VDC, 1A external power supply
28-070-01
1/2" Phillips screws (2)
Tweeker (small screwdriver)
CIA111 and CIA114 User’s Manual
