AVTrac Extensions • Kit Contents
1
Kit Contents
The AVTrac Extension kit is available as a 4 feet (1.22 meter) extension for the AVTrac system. An optional rubber
strip inlay kit (part number
70-670-01) can be purchased separately.
Check contents of each box to ensure all items are present.
Plastic Template (1)
Side Ramp (2)
Aluminum
Base Track (1)
Aluminum
Cover Track (1)
Installation
Guide
5/32" Masonry Bit (1) and
3/16" Masonry Screws
Figure 1.
Kit Contents
Contents checklist
4 feet (1.22 m) Aluminum Base Track (1)
4 feet (1.22 m) Aluminum Cover Track (1)
4 feet (1.22 m) Side Ramps (2)
Plastic Wall Base Trim Template (1)
3/16 inches Masonry Screws (10)
5/32 inches Masonry Drill Bit (1)
Installation Guide (1)
NOTE: If you are using the AVTrac extensions with the complete AVTrac system, please
consult the AVTrac User Guide or an Extron Representative for instructions and advice
about compatibility.
