Extron Electronics AVTrac Extension Kit User Manual
Page 13
AVTrac Extensions • Finishing Up
7
4.
If the extension kit abuts the wall, use the provided
template to trim the wall base board so that it fits
snugly around the track.
Figure 14.
Use the template to cut the base board.
5.
Attach the base board to the wall.
Figure 15.
Reattach the base board to the wall.
6.
To insert a carpet inlay, cut a strip of the finished
carpeting and glue or tape it to the cover track
raceway.
For an alternative rubber finish, use the optional
rubber strip inlay kit (part number
70-670-01).
Figure 16.
Attach carpet to the track raceway.
