Extron Electronics CVEQ1, CVEQ1 WM, CVEQ1 AAP - Manual (Page 5)

CVEQ1 Series • Quick Start Guide
Quick Start Guide — CVEQ1 Series, cont’d
v CVEQ1 Series • Table of Contents
Chapter 1 • Introduction ......................................................... 1-1
About the CVEQ1, CVEQ1 WM, and CVEQ1 AAP ... 1-2
Features ...................................................................................... 1-2
Chapter 2 • Installation, Setup, Operation ................ 2-1
UL Requirements ................................................................... 2-2
Preparing the Site and Installing the Wall Box ..... 2-2
Front Panel Features and Cabling ................................ 2-5
Rear/Bottom/Side Panel Features and Cabling ...... 2-6
Top/Side Panel Features and Adjustments ............... 2-8
Mounting the CVEQ1 AAP ............................................. 2-10
Mounting the CVEQ1 WM .............................................. 2-11
Appendix A • Specifications , Part Numbers,
and Accessories ..............................................................................A-1
Specifications ..........................................................................A-2
Included Parts .........................................................................A-4
Accessories ...............................................................................A-4
Cables ..........................................................................................A-4
Appendix B • Dimensions and Templates ...................B-1
Dimensions ...............................................................................B-2
Template ....................................................................................B-3
Table of Contents
68-544-01 Rev. C
09 05
All trademarks mentioned in this manual are the properties of their respective owners.
QS-2
Step 7
While watching the display, adjust the video gain and equalization
by using the rotary Gain and Equalize controls. An oscilloscope can
be used to achieve a more precise adjustment. See “Top/Side Panel
Features and Adjustments” in chapter 2.
Step 8
For the CVEQ1 AAP or CVEQ1 WM,
A.
Disconnect the line driver’s power supply at the source end (not
at the line driver).
B. Disconnect the input and output devices’ power.
C. For the CVEQ1 WM, secure the faceplate onto the UL-approved
electrical wall box in the wall or furniture.
For the CVEQ1 AAP, secure the wallplate/faceplate that the
CVEQ1 AAP is attached to onto the UL-approved electrical wall
box in the wall or furniture.
D. Restore power to the line driver and to input and output devices.
