CVEQ1 Series • Specifications, Parts, Accessories
Specifications, Parts, and Accessories, cont’d
CVEQ1, CVEQ1 WM, CVEQ1 AAP
B
Appendix B
Dimensions and Templates
Dimensions
Template
A-4
Included Parts
These items are included in each order for a CVEQ1,
CVEQ1 AAP, or CVEQ1 WM:
Included parts Part number
CVEQ1 60-360-02
CVEQ1 AAP (gray, black, white) 70-146-02, -12, -22
CVEQ1 WM (gray, black, white) 60-435-02, -12, -22
12 VDC, 1 A max. external power supply 70-055-01
CVEQ1/CVEQ1 AAP/CVEQ1 WM
User’s Manual
Accessories
Accessories Part number
BNCM-RCAF adapters (10) 100-234-01
3.5 mm 5-pole captive screw connector 10-319-10
AAP 102 2 gang wall plate (gray, black, white) 60-300-01,-02,-03
AAP 104 4 gang wall plate (gray, black, white) 60-301-01,-02,-03
AAP 201 half rack width, 1U high faceplate 60-302-01
AAP 202 half rack width, 2U high faceplate 60-303-01
1-gang mounting bracket/mud ring
(gray, black, white) 70-086-05, -15, -25
P/S 100 universal power supply 60-357-01
P/S 150 universal power supply 60-432-01
Cables
Super high resolution cables Part number
RG6-1, 6’ (1.8 m), 12’ (3.7 m) 26-383-12, -07
RG6-1, 50’ (15.2 m), 100’ (30.5 m) 26-383-05, -03
RG6-1, 500’ (152.4 m) bulk 22-098-02
or
or
Warranty ........................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
