Interface for the PROFIBUS MIQ/(A-)PR
18 ba76020e01 01/2012
Module monitoring A two-color LED (for position of the LED, see section 3.2) is used for
monitoring the PROFIBUS module.
3.3 GSD file
The GSD file contains all necessary information on the PROFIBUS
module and is required by the configuration program of the PROFIBUS
master.
The GSD file for the IQ S ENSOR N ET is found on the CD-ROM provided
(file name: IQMC06D1.GSD). The current GSD file is also provided on
the Internet under www.ysi.com.
Monitoring function Color Flashing
frequency
ASIC and FLASH ROM error Red 2 Hz
Module not initialized Green 2 Hz
Module initialized and in operation Green 1 Hz
RAM error Red 1 Hz
DPRAM error Red 4 Hz
