MIQ/(A-)PR Interface for the PROFIBUS
9 ba76020e01 01/2012
3 Interface for the PROFIBUS
The MIQ/(A-)PR PROFIBUS module enables to connect the
IQ S
ENSOR N ET with all the sensors connected to it to the digital
connection of a superordinate process control.
The AnyBus-S module for PROFIBUS DP of the HMS INDUSTRIAL
NETWORKS AB company is mounted in the MIQ/(A-)PR for this.
Note
Further instructions for the installation and operation of a PROFIBUS
network is given on the Internet under www.profibus.com and
www.hms-networks.com.
3.1 Scope of delivery
The scope of delivery of the MIQ/(A-)PR module comprises:
 MIQ/PR or MIQ/A-PR
 PROFIBUS module, AnyBus-S module for PROFIBUS-DP,
mounted in the MIQ/(A-)PR module
 4 x screwed cable glands with seals and blind plugs
 2 x ISO blind nuts (M4)
 2 x cheese-head screws (M4x16) with plastic washer
 1 x contact base
 2 x plastic tapping screws for fixing the contact base
 CD-ROM containing GSD file
 Operating manual.
