9 - 2 ba76034e01 01/2012
9.1.2 Informative messages
The MIQ/IC2 current input module does not send any info messages.
9.2 Status info
The status info is a coded piece of information on the current status of
a sensor. Each sensor sends this status info to the controller. The sta-
tus info of sensors consists of 32 bits, each of which can have the value
0 or 1.
General structure of the
status info
The bits 0 - 15 are reserved for general information.
The bits 16 - 21 are reserved for internal service information.
The status info can be obtained as follows:

via a manual query in the menu, Einstellungen/Settings/Service/
Liste aller Teilnehmer (see system operating manual)
 via an automatic query
– of a superior process control (e. g. when connected to the Profi-
bus)
– of the IQ Data Server (see IQ S ENSOR N ET Software Pack ope-
rating manual)
Note
The evaluation of the status info, e. g. in the case of an automatic que-
ry, has to be made individually for each bit.
MIQ/IC2
status info
ES1381 Component hardware defective
* Contact service
Message code Message text
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 (general)
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 (internal)
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Status bit Explanation
Bit 0 Component hardware defective
Bit 1-31 -
