MIQ/IC2
Technical data
7 - 1
ba76034e01
01/2012
7
Technical data
Note
General technical data on MIQ modules are given in the T
ECHNICAL
DATA
chapter of the IQ S
ENSOR
N
ET
system operating manual.
Electrical data
Instrument safety
Terminal connections
Nominal voltage
Max. 24 VDC via the IQ S
ENSOR
N
ET
(for
details, see the T
ECHNICAL
DATA
chapter of
the IQ S
ENSOR
N
ET
system operating
manual)
Power consumption
0.2 ... 4.6 W
0.2 W: without supplying any power supply/
isolator
≤
2.4 W: with one power supply/isolator
≤
4.6 W: with two power supply/isolators
Protective class
III
Applicable norms
– EN 61010-1
– UL 3111-1
– CAN/CSA C22.2 No. 1010.1
IQ S
ENSOR
N
ET
connec-
tions
2
Additional connectable SENSORNET termi-
nator (terminating resistor)
Current inputs
(0/4 ... 20 mA)
2
Connector for power
supply/isolator
1
Terminal type
Screw-type terminal strip, accessible by
opening the lid
Terminal ranges
Solid wires:
0.2 ... 4.0 mm
2
AWG 24 ... 12
Flexible wires:
0.2 ... 2.5 mm
2
Line cross-section of ca-
bles carrying mains volt-
age
Europe:
1.5 ... 4.0 mm
2
USA:
AWG 14 ... 12
Cable feeds
4 cable glands M16 x 1.5 on the underside
of the module
