9.2 Status info
The status info is a coded piece of information on the current status of
a sensor. Each sensor sends this status info to the controller. The sta-
tus info of sensors consists of 32 bits, each of which can have the value
0 or 1.
Status info,
general structure
The bits 0 - 15 are reserved for general information.
The bits 16 - 21 are reserved for internal service information.
You obtain the status info:
 via a manual query in the Einstellungen/Settings/Service/List of all
components menu (see system operating manual)
 by an automated query
– from a superordinate process control (e. g. when connected to
the Profibus)
– from the IQ Data Server (see IQ S ENSOR N ET Software Pack
operating manual)
Note
The evaluation of the status info, e.g. in the case of an automated
query, has to be made individually for each bit.
FDO
®
70x IQ (SW)
Status info
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 (general)
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 (internal)
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Status bit Explanation
Bit 0 Component hardware defective
Bit 1 Sensor cap missing, untight, depleted or defective
Bit 2-31 -
