Technical data FDO
®
70x IQ (SW)
7 - 2 ba76014e01 02/2012
7.3 General data
Dimensions
Weight (without sensor
connection cable)
Connection technique Connection via SACIQ (SW) sensor connection cable
Material
* Stainless steel can be corrodible if there are chloride concentrations
of 500 mg/L or more. For applications in such media we recommend to
use the SW sensors.
59.5
40.0
276
34
400
400
39.7
39.7
FDO 70x IQ SW:
FDO 70x IQ:
Socket SACIQ...
Socket SACIQ...
FDO
®
70x IQ Approx. 900 g
FDO
®
70x IQ SW Approx. 1500 g
Shaft:
– FDO
®
70x IQ
– FDO
®
70x IQ SW
V4A stainless steel 1.4571 *
POM
Plug head connector housing POM
Sensor head POM and PVC
Sensor cap See section 7.5 or section 7.6
Plug, 3-pole ETFE (blue) Tefzel
®
Fixing ring POM
Protective hood
(FDO
®
70x IQ SW)
POM
