FDO
®
70x IQ (SW) Commissioning
3 - 5 ba76014e01 02/2012
Carrying out settings Using
s
, switch from the measured value display to the main menu of
the settings. Then navigate to the setting menu (setting table) of the
sensor. The exact procedure is given in the relevant IQ S
ENSOR N ET
system operating manual.
Temp. adjustment -1.5 K ... +1.5 K The temperature compensation enables the
temperature display to be balanced (shifting
of the zero point by ±1.5K).
Notes:
 Due to the thermal capacity of the sensor,
it is necessary to place it in a container
with at least 2 liters of water.
 Leave the sensor in this container for at
least 15 minutes while stirring
occasionally until the balancing can be
performed.
With temperature differences between the
water and sensor > 10 °C, leave the
sensor for at least 1 hour in this container
while stirring occasionally until the
balancing can be performed.
Salinity
 On
 Off
Determines whether the entered salinity
should be taken into account.
Salinity input 2.0 ... 70.0 The entry of the salinity enables a salt con-
tent correction that compensates for the
effect of salt contents > 0.1 % on the oxygen
measurement.
The salt content correction is recommended
for measurements in salt-contaminated
wastewater (salinity
≥ 2.0 corresponding to a
conductivity of
≥ 3.4 mS/cm at a reference
temperature TREF = 20 °C).
Sensor cap data
 Do not download
 Transmit to log
book
Generates a log book message with all data
stored in the sensor cap when the settings
are quit with Save and quit (see section 1.2).
When opening the menu again the setting is
reset to Do not download.
Save and quit The system confirms the saving of the set-
tings and the display switches to the next
higher level.
Quit The display switches to the next higher level
without saving the new settings.
Setting Selection/values Explanation
