Bell & Gossett HT 320B SM Models “OE” Straight Tube, Fixed Tubesheet Heat Exchangers - Manual (Page 4)

PRINTED IN U.S.A. 5-95
Bell & Gossett
Morton Grove, IL, U.S.A.
For further information, contact Bell & Gossett Heat Transfer Products, 175 Standard Parkway, Cheektowaga, NY 14227,
Phone (716) 862-4171 — Facsimile (716) 862-4176.
When ordering replacement parts give name of part,
National Board Number and factory number from nameplate.
FRONT
HEAD
FRONT
HEAD
GASKET
NAMEPLATE
CASING AND TUBE
BUNDLE ASSEMBLY
REAR
HEAD
GASKET
REAR
HEAD
CROSS SECTIONAL VIEW OF
FIXED TUBE CONSTRUCTION
