Bell & Gossett HS 504F Series 1141 Temperature Regulators - Manual (Page 11)

THERMOSTATIC
BULB
RELIEF
VALVE
HOT
WATER
OUTLET
DRAIN AND
BLOW-OFF
COLD
WATER
INLET
STORAGE
HEATER
TO
TRAP
VACUUM
BREAKER
TEMPERATURE
REGULATOR
STEAM
INLET
"Y" STRAINER
DRIP
TRAP
THERMOMETER
WITH
STORAGE
TANK
WITHOUT
STORAGE
TANK
COLD
WATER
INLET
CHECK VALVE
MIN.
15 INCHES
VACUUM BREAKER
"Y"
STRAINER
TEMPERATURE
REGULATOR
STEAM
TRAP
SUPPLY
VALVE
DRIP
TRAP
CIRCULATOR PUMP USED WITH
STORAGE TANK
HOT WATER OUTLET
THERMOSTATIC BULB
LOCATION WHEN USED
WITH STORAGE TANK
TEMPERATURE
REGULATOR
STEAM INLET
TO TRAP
WATER LINE
THERMOSTATIC
BULB
Figure No. 15— Controlling steam coil in storage tank
Figure No. 16 — Controlling instantaneous water heater
with or without buffer storage tank.
Figure No. 17 — Controlling steam table
11
TYPICAL INSTALLATIONS
