OPERATING INSTRUCTIONS

WARNING: Potential for escape of hot fluids. Use

only B&G companion readout probes to obtain

accurate and safe readout from the readout valve. Fail-

ure to follow these instructions could result in serious

personal injury or death and property damage.

WARNING: Hot fluids may escape. When moni-

toring system flow, care must be exercised to

avoid skin or eye contact with liquids that may escape.

Failure to follow these instructions could result in seri-

ous personal injury or death and property damage.

1. Connect readout probes to pressure or differential pres-

sure meter with the male thread connection. Make sure

the connection is tight.

WARNING: Hot fluids under pressure. Before

inserting readout probe, slowly loosen the protec-

tive cap to vent off any pressure accumulation. The

protective cap must be replaced when readout probe

is removed. Failure to follow these instructions could

result in serious personal injury or death and property

damage.

2. Insert the full length of the probe into each readout

valve and tighten the ferrule nut. It is not uncommon

for a small amount of system fluid to escape during the

insertion.

3. Read pressures according to instructions supplied with

the pressure measuring device.

4. If the measuring device is not to be left permanently

connected to the readout valves, remove the readout

probes from the readout valve and reinstall protective

caps. If left in place, periodically inspect the probes for

leakage and replace if necessary.

SERVICE INSTRUCTIONS

After use, inspect probe for blockage by visual or other

means. Periodically inspect for damage and replace if

necessary.

WARNING: Leakage, corrosion or indications of

damage are signs of an impending serious failure

of the readout valve or readout probe. Periodically

inspect the readout valve or readout probe for signs of

leakage or corrosion. Replace if noted. Failure to follow

these instructions could result in serious personal injury

or death and property damage.
