Acer AR160 F1 User Manual
Page 25
9
3
JPW3
8-pin processor power connector
4
JPW2
8-pin processor power connector
5
JPW1
20-pin ATX power connector
6
JPI
2
C
Power supply SMBus I
2
C header
7
FAN1
Chassis fan 1
8
FAN2
Chassis fan 2
9
BATTERY
CMOS battery
10
FAN3
Chassis fan 3
11
P2-DIMM1B,
P2-DIMM1A,
P2-DIMM2B,
P2-DIMM2A,
P2-DIMM3B,
P2-DIMM3A
DDR3 sockets for processor 2
12
FAN4
Chassis fan 4
13
I-SATA0 -
I-SATA5
SATA ports
Note: I-SATA5 is reserved for an installed optical
drive.
14
JF1
Front panel connector
15
JOH1
Overheat warning header
16
T-SGPIO1
Serial General Purpose Input/Output header 1
17
T-SGPIO2
Serial General Purpose Input/Output header 2
18
USB2/3
Universal Serial Bus (USB) headers 2/3
19
JL1
Chassis intrusion header
20
FAN5
Chassis fan 5
21
USB4/5
USB headers 4/5
No.
Connector
Description
