PAM8407
Document number: DS36815 Rev. 1 - 2
6 of 12
www.diodes.com
January 2014
© Diodes Incorporated
PAM8407
New Product
A PRODUCT LINE OF
DIODES INCORPORATED
2x3W Stereo Differential Input Class D Audio Amplifier
with Up/Down Volume Control
Performance Characteristics
(@
T
A
= +25°C, V
DD
= 5V, Gain = 24dB, R
L
= L(33μH) + R + L(33μH), unless otherwise noted.
)
Quiescent Current Vs. Supply Voltage OSC Frequency Vs. Supply Voltage
Rdson Vs. Output Current Up/Down Volume Control (dB)
240
245
250
255
260
265
270
2
3
4
5
6
Fr
equency(kHz)
Supply Voltage(V)
0
50
100
150
200
250
300
350
400
0
500
1000
1500
Rdson(mohm)
Output Current(mA)
3
4
5
6
7
8
9
10
2
3
4
5
6
Quiescen
t
Curr
en
t(mA)
Supply Voltage(V)
PMOS
NMOS
STEP Gain STEP Gain STEP
Gain
1
24
12
7.5 23
-10
2
22.5
13
6 24
-12
3
21
14
4.5 25
-14
4
19.5
15
3 26
-16
5
18
16
1.5 27
-18
6
16.5
17
0
28
-20
7
15
18
-1.5
29
-22
8
13.5
19
-3
30
-24
9 12* 20 -4.5
31
-26
10
10.36
21
-6
32
-80
11
9
22
-8
-
-
*Default Gain=12dB
