HIGH POWER AUDIO

Description

The PAM8124 is a 15W efficient, Class-D audio power amplifier for
driving stereo speakers in a single-ended configuration; or a mono
speaker in a bridge-tied-load configuration. The PAM8124 can drive
stereo speakers (SE) as low as 4Ω. Due to the low power dissipation
and high efficiency, up to 95%, the device can be used without any
external heat sink when playing music.

The gain of the amplifier is controlled by 2 gain selectable pins,
offering 20dB, 26dB, 32dB, and 36dB gain selections.

The PAM8124 is available in a TSSOP-24-EP package.

Features

30W/Ch into 8Ω BTL Load from 22V Supply

15W/Ch into 4Ω SE Load from 22V Supply

10W/Ch into 8Ω SE Load from 24V Supply

Operate from 10V to 26V

Single-Ended Analog Inputs

Supports Multiple Output Configurations:
ƒ

2-Ch Single-Ended (SE, Half-Bridge)

ƒ

1-Ch Bridge-Tied Load (BTL, Full-Bridge)

Four Selectable Fixed-gain Settings

No Pop Noise for Start-up and Shut-down Sequences

Internal Oscillator (No External Components Required)

High Efficient Class-D Operation Eliminates Need for Heat Sinks

Thermal and Short-Circuit Protection with Auto Recovery

Space-Saving Surface-Mount TSSOP-24EP Package

• Pb-Free

Package

Pin Assignments

TSSOP-24-EP

PVCCL

SDN

PVCCL

MUTE

LIN

VCM

AGND
AGND

PVCCR

VCLAMP

PVCCR

PGNDR

PGNDR

ROUT

BSR

GAIN1

GAIN0

AVCC

BSL

LOUT

PGNDL

PGNDL

PAM

8

1

2

4

XX
XY
W

W

L

L

17

1

2
3
4
5
6
7
8
9

10
11
12

13

14

15

16

18

19

20

21

22

23

24

RIN

SE_BTL


Applications

• Televisions

Home Sound Systems

• Active

Speakers


Typical Applications Circuit

PVCCL

1

SDN

2

PVCCL

3

MUTE

4

LIN

5

RIN

6

VCM

7

AGND

8

AGND

9

PVCCR

10

VCLAMP

11

PVCCR

12

PGNDR

13

PGNDR

14

ROUT

15

BSR

16

GAIN1

17

GAIN0

18

SE_BTL

19

AVCC

20

BSL

21

LOUT

22

PGNDL

23

PGNDL

24

U1

SD

Mute

C1
1uF

C3
1uF

C5

220nF

L1
33uH

G0

C2

1uF

G1

R1

4.7K

C7
470uF

L_out1

8ohm

C6
220nF

L2
33uH

C4

1uF

R2
4.7K

C8
470uF

R_out1

8ohm

L_in

R_in

PA

M

81

24

10V_to_26V

10V_to_26V

SE_BTL

10V_to_26V
